Corken  |  SKU: ZQ FF075

FF075CD6A (Corken) FF075 Autogas Bare Pump

$5,89754
Taxes and shipping calculated at checkout.

FF075 Autogas bare pump 1-1/2 Inlet x 1 ANSI flange

The Corken FF075CD6A FF075 Autogas Bare Pump is a heavy-duty regenerative turbine pump designed specifically for Autogas / LPG transfer applications. It’s part of the Corken Coro-Flo® series and is commonly used in:

  • Autogas dispenser systems
  • LPG cylinder filling
  • Bulk propane transfer
  • Vapor return / recirculation systems
  • Fleet fueling stations
Code Meaning
FF075 Frame-mounted 075-series pump
C NEMA C-face motor compatibility
D Bronze impeller / steel shaft configuration
6 Silicon carbide seal seat
A Buna-N elastomers



The “FF” version is the frame-mounted configuration, meaning:

  • No motor included
  • Requires external motor/coupling setup
  • Commonly mounted on a baseplate with guard and Lovejoy coupling
Attribute Value
Pump Type Regenerative turbine
Fluid LPG / Propane / Autogas
Inlet Size 1-1/2" ANSI 300 RF
Outlet Size 1" ANSI 300 RF
Max Differential Pressure 200 PSI @ 60Hz
Max Working Pressure 400 PSI
Flow Range 10–40 GPM
Typical Flow ~22.5 GPM @ 145 PSI
Temperature Range -25°F to 225°F
Bare Pump Weight ~63 lbs
Max Driver Size 20 HP
Typical Motor 5–7.5 HP, 3450 RPM
